Formfaktor |
Small Form Factor |
Betriebssystem |
Windows 10 Pro 64
Windows 10 Home 64
Windows 7 Professional 64
Windows 7 Professional 64 (erhältlich über Downgrade-Rechte von Windows 10 Pro)
HP Linux-fähig
|
Prozessorproduktfamilie |
Intel® Core™ i7-Prozessor; Intel® Core™ i5-Prozessor |
Prozessoren |
Intel® Core™ i7-6700 mit Intel HD-Grafikkarte 530 (3,4 GHz, bis zu 4 GHz mit Intel Turbo Boost-Technologie, 8 MB Cache, 4 Kerne); Intel® Core™ i5-6600 mit Intel HD-Grafikkarte 530 (3,3 GHz, bis zu 3,9 GHz mit Intel Turbo Boost-Technologie, 6 MB Cache, 4 Kerne); Intel® Core™ i5-6500 mit Intel HD-Grafikkarte 530 (3,2 GHz, bis zu 3,6 GHz mit Intel Turbo Boost-Technologie, 6 MB Cache, 4 Kerne) |
Chipsatz |
Intel® C236 |
Maximale Speicherkapazität |
Bis zu 64 GB DDR4-2133 ungepufferter SDRAM Hinweis zum Standardspeicher: Übertragungsrate von bis zu 2133 MT/s |
Speichersteckplätze |
4 UDIMM |
Laufwerks-Controller |
Das integrierte SATA (4 Anschlüsse, 6 Gbit/s) mit RAID 0 (Stripeset-Array) und RAID 1 (gespiegeltes Array) wird nur auf Windows-Betriebssystem unterstützt. Erfordert identische Festplatten (Geschwindigkeiten, Kapazität, Schnittstelle). Integriertes RAID 0, 1 (Datenkonfiguration) für PCIe SSDs. |
Interner Speicher |
500 GB Bis zu 4 TB SATA (7200 U/min)
Bis zu 500 GB SATA SED
128 GB Bis zu 1 TB SATA SSD
Bis zu 256 GB SATA SE SSD
Bis zu 1 TB SATA SSHD
128 GB Bis zu 512 GB HP Z Turbo Drive G2 (NVMe PCIe SSD) |
Optische Speicher |
HP Slim DVD-ROM-Laufwerk; HP Slim SuperMulti DVD-RW-Laufwerk; HP Slim Blu-ray Writer |
Zusätzlicher Speicher |
SD-Medienkartenleser (optional) |
Laufwerkschächte (intern) |
1 x 3,5" (8,9 cm); 1 x 2,5" (6,3 cm) 1 gemeinsam genutzter 3,5"-Schacht (8,9 cm) mit externem 3,5"-Schacht (8,9 cm) |
Laufwerkschächte (extern) |
1 gemeinsam genutzter 8,9-cm-Schacht (3,5 Zoll) mit internem 8,9-cm-Schacht (3,5 Zoll); 1 Slim ODD |
Verfügbare Grafikkarten |
Integriert: Intel® HD-Grafikkarte 530; Intel® HD-Grafikkarte P530
Professionelle 2D-Leistung: NVIDIA® NVS™ 310 (1 MB); NVIDIA® NVS™ 315 (1 GB); NVIDIA® NVS™ 510 (2 GB)
3D-Leistung im Einstiegsbereich: AMD FirePro™ W2100 (2 GB); NVIDIA® Quadro® K420 (2 GB); NVIDIA® Quadro® K620 (2 GB)
Mid-Range-3D-Leistung: NVIDIA® Quadro® K1200 (4 GB) |
Erweiterungssteckplätze |
1 PCIe Gen3 x16; 2 PCIe Gen3 x1 (x1-Anschluss); 1 PCIe Gen3 x4 (x16-Anschluss) Alle Steckplätze sind Low-Profile |
Ports und Anschlüsse |
Vorderseite: 2 USB 3.0; 2 USB 2.0; 1 Kopfhörer; 1 Mikrofon
Rückseite: 6 USB 3.0; 3 DisplayPort 1.2; 1 seriell; 2 PS/2; 1 RJ-45; 1 Audioeingang; 1 Audioausgang
Intern: 1 USB 3.0; 3 USB 2.0 1 USB 3.0-Anschluss und
3 USB 2.0-Anschlüsse, verfügbar als 2 separate 2x10-Header (3.0 x1, 2.0 x1) und 2x5-Header (2.0 x2).
Unterstützt ein internes HP USB 2.0-Anschluss-Kit und einen USB 3.0-Medienkartenleser. |
Kommunikation |
Intel® I219LM PCle GbE integriert; Intel® Ethernet I210-T1 PCIe NIC (optional) |
Audio
|
Realtek HD ALC221-VB Audio integriert |
Stromversorgung |
240 W, Wirkungsgrad 92 %, Weitbereich, Active PFC |
Eingabegerät |
HP Wireless-Business-Tastatur, flach; HP SmartCard-USB-CCID-Tastatur; HP USB-Business-Tastatur, flach; HP PS/2-Business-Tastatur, flach
HP SpaceMouse Pro USB 3D: HP USB-Lasermaus, 1.000 dpi; Optische HP USB-Maus mit 3 Tasten; Optische HP USB-Maus; HP PS/2-Maus; 3Dconnexion CAD-Maus |
Sicherheit |
HP Solenoid-Schloss und Gehäusesensor (optional); HP Business PC Security Lock Kit (optional); HP UltraSlim Kabelsperre-Kit (optional) |
Software |
HP Performance Advisor; HP Remote Graphics Software (RGS) 7.1; PDF Complete Corporate Edition; Cyberlink Power DVD und Power2Go; HP PC Hardware Diagnostics UEFI; HP Client Security-Software; Erwerb von Office |
Abmessungen |
100 x 337 x 384 mm Standard-Desktop-Bauform |
Gewicht |
6 kg Die exakten Gewichtsangaben hängen von der Konfiguration ab |
Konformität mit Energieeffizienz |
ENERGY STAR®-zertifizierte und EPEAT®-registrierte Konfigurationen verfügbar |
Umweltstandards |
Halogenarm |
Kompatible Bildschirme |
HP Z27s IPS-UHD-Display mit 68,6 cm (27 Zoll) Diagonale; HP Z27q IPS-5K-Display mit 68,6 cm (27 Zoll) Diagonale; HP Z24s IPS-UHD-Display mit 60,45 cm (23,8 Zoll) Diagonale; HP Z Display Z30i IPS-Monitor mit 76,2 cm (30 Zoll) Diagonale und LED-Hintergrundbeleuchtung; HP Z27n IPS-Display mit 68,6 cm (27 Zoll) Diagonale und schmaler Blende; HP Z24n IPS-Display mit 61 cm (24 Zoll) Diagonale und schmaler Blende; HP Z23n IPS-Display mit 58,4 cm (23 Zoll) Diagonale; HP Z22n IPS-Display mit 54,6 cm (21,5 Zoll) Diagonale; HP DreamColor Z24x Professional-Display; HP DreamColor Z27x Professional-Display |
Garantie |
3 Jahre eingeschränkte Garantie auf Ersatzteile, Arbeitszeit und Vor-Ort-Reparatur (3-3-3). Die allgemeinen Geschäftsbedingungen variieren je nach Land. Es gelten bestimmte Einschränkungen und Ausschlussklauseln. |
