Operating System |
Windows 10 Pro for Workstations 64 – HP recommends Windows 10 Pro.
Windows 10 Pro for Workstations
Windows 10 Home Single Language 64
FreeDOS 2.0 |
Processor Family |
7th Generation Intel® Core™ i7 processor (i7-7500U, i7-7600U);
8th Generation Intel® Core™ i7 processor (i7-8650U, i7-8550U);
8th Generation Intel® Core™ i5 processor
|
Processors |
Intel® Core™ i7-7500U with Intel® HD Graphics 620 (2.7 GHz base frequency, up to 3.5 GHz with Intel® Turbo Boost Technology, 4 MB cache, 2 cores);
Intel® Core™ i7-7600U with Intel® HD Graphics 620 (2.8 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 4 MB cache, 2 cores);
Intel® Core™ i5-8250U with Intel® UHD Graphics 620 (1.6 GHz base frequency, up to 3.4 GHz with Intel® Turbo Boost Technology, 6 MB cache, 4 cores);
Intel® Core™ i7-8550U with Intel® UHD Graphics 620 (1.8 GHz base frequency, up to 4 GHz with Intel® Turbo Boost Technology, 8 MB cache, 4 cores);
Intel® Core™ i7-8650U with Intel® UHD Graphics 620 (1.9 GHz base frequency, up to 4.2 GHz with Intel® Turbo Boost Technology, 8 MB cache, 4 cores) |
Maximum Memory |
Up to 32 GB DDR4-2133 non-ECC SDRAM
Standard memory note: Transfer rates up to 2133 MT/s |
Memory Slots |
2 SODIMM |
Internal Storage |
up to 128 GB M.2 SATA SSD
up to 512 GB M.2 SATA FIPS SSD
256 GB up to 512 GB HP Z Turbo Drive PCIe® NVMe™ SSD
256 GB up to 2 TB PCIe® NVMe™ M.2 SSD
up to 512 GB PCIe® NVMe™ M.2 SED SSD |
Display |
35.56 cm (14") diagonal 4K IPS anti-glare (3840 x 2160);
35.56 cm (14") HP DreamColor 14" diagonal 4K IPS anti-glare touch screen (3840 x 2160) |
Available Graphics |
Integrated: Intel® HD Graphics 620; Intel® UHD Graphics 6206
Discrete: NVIDIA® Quadro® M620 (2 GB GDDR5 dedicated) |
Expansion Slots |
1 smart card reader; 1 SD media card reader
SD supports next generation secure digital and is backward compatible to SDHC, SDXC |
Ports and Connectors |
Left side: 1 headphone/microphone combo
Right side: 1 power connector; 1 HDMI 1.4; 1 USB 3.0 (charging); 2 USB 3.1 Type-C™ Thunderbolt™ 3 (DisplayPort™ 1.2) |
Communications |
WLAN:
HP hs3110 HSPA+ Intel® Mobile Broadband Module;
Intel® Dual Band Wireless-AC 8265 802.11a/b/g/n/ac (2x2) Wi-Fi® and Bluetooth® 4.2 Combo5 |
Camera |
720p HD webcam with IR (front-facing);
720p HD webcam (world-facing camera) |
Power |
90 W external AC power adapter;
65 W external AC power adapter |
Input Device |
Backlit keyboard with function key control
Image sensor clickpad with on/off button, two-way scroll, gestures, two buttons; Extra large clickpad with on/off button, two-way scroll, gestures, two buttons |
Security |
Absolute Persistence Module; DriveLock and Automatic DriveLock; HP Spare Key; RAID (available as a configurable option); Serial, parallel, USB enable/disable (via BIOS); Setup password (via BIOS); Power-on password (via BIOS); HP Client Security Suite Gen 3; HP Security Manager; HP Credential Manager; HP Password Manager; HP Power On Authentication; HP Device Access Manager; Trusted Platform Module TPM 2.0 Embedded Security Chip; Support for chassis padlocks and cable lock devices; Integrated hood sensor |
Software |
HP Mobile Workstations are shipped with a variety of software titles including: HP Performance Advisor, HP Remote Graphics Software, HP Client Security, HP Drive Encryption (FIPS 140-2), Microsoft Security Essentials, Microsoft Defender, HP ePrint Driver, HP PageLift. Please refer to this product's quick spec document for a full list of preinstalled software. |
Dimensions |
36.45 x 22.7 x 2.03 cm (laptop mode); 36.45 x 22.7 x 1.46 cm (tablet mode |
Weight
|
Starting at 2.17 kg (laptop mode); Starting at 1.65 kg (tablet mode) |
Energy Efficiency Compliance |
ENERGY STAR® certified and EPEAT® registered configurations available |
Environmental Certification |
Low halogen |
Warranty |
3 year (3-3-0) limited warranty and service offering includes 3 years of parts and labor. Terms and conditions vary by country. |
